Syscal Pro

The Syscal Pro is an all-in-one multinode resistivity and induce polarization sounding and profiling system for environmental and engineering geophysical studies. The Syscal Pro gathers a 10 channels receiver and a 250 W internal transmitter which make it the more powerful system of the Syscal range.

Compact, easy-to-use and field proof, the Syscal Pro measures both resistivity and chargeability. It is ideal for environmental and civil engineering applications such as depth-to-rock determination, weathered bedrock mapping. With a maximal output voltage of 2000Vpp, the Syscal Pro is very adapted to detect deep fault in fractured aquifers or to characterize the depths and thickness of the groundwater aquifers.

Several options are available with the Syscal Pro such as the Fullwave mode to record complete time series of measured voltages during an acquisition and the Remote mode that allow for controlling automatically the Syscal Pro through a PC for monitoring purposes.

Several additional accessories are also available to use the Syscal Pro to increase the transmitter power to 1200 W, to perform measurements in borehole, to test the 12V batteries, to communicate via wifi or to upload data on a SD card.

View Syscal Pro Switch

Request a sale quote Compare resistivity meter

Natural hazard

Transmitter
Voltage	0-2000 Vpp
Current	0-2500 mA
Power	Auto controled Internal 250W DC/DC converter, and 1200W with external AC/DC
Battery	internal battery or external 12V

Receiver
Pulse duration	250ms, 500ms, 1s, 2s, 4s or 8s
Channels	10 true differential inputs
Input impedance	100 MOhms
Input voltage	15V, automatic gain, input protection 1000V
GPS	GPS input for coordinate and synchronisation
Resolution / Accuracy	1 µV / 0.2%
Readings	Resistivity, Self-potential, Induced polarisation (Up to 20 windows), Quality control and optional full waveform
Noise rejection	Power line rejection, SP linear drift correction
Storage	44800 readings, up to 8 hours full waveform, stored on solid state memory
